Know Your P20 Mold Steel Before You Order
P20 is a mold-steel family used for plastic tooling. Evaluate P20 mold steel properties against the exact supplied product, condition, geometry and finish requirement. A family name does not establish one hardness or an automatic European substitute.
P20 Mold Steel Family
SIJ lists SIMOLD 2311 / material number 1.2311 / DIN 40CrMnMo7 as an approximate P20 comparison. Confirm the actual purchase specification and supplied condition.
3 Variants to Separate
Keep 1.2311, sulfur-modified 1.2312 and nickel-modified 1.2738 distinct. Review suitability for your required tool surface and supply scope before substitution.
P20 Mold Steel Composition
| Element | SIMOLD 2311 listed wt.% |
|---|---|
| C | 0.40 |
| Si | 0.40 |
| Mn | 1.50 |
| Cr | 1.90 |
| Mo | 0.20 |
SIJ producer catalog reference for SIMOLD 2311. Listed analysis is not a test report from your lot or a universal P20 acceptance range.
Connect Stock State to Your Finish
| Decision | Your required input |
|---|---|
| Supplied stock | Exact product, actual state and agreed material evidence. |
| Fitting route | Controlled datums, retained stock and any further process. |
| Working surface | Defined finish or sample, acceptance and protection. |
Confirm the actual supplied condition before machining or proposing another thermal cycle.
Compare Selected Alloy Content
Selected producer-listed analysis · wt.% · common axis 0–6%
P20 / SIMOLD 2311 · C
0.40%
H13 / W302 · C
0.39%
P20 / SIMOLD 2311 · Cr
1.90%
H13 / W302 · Cr
5.20%
03%6%
Chemistry comparison only. These bars do not measure toughness, wear resistance, hardness or your material lot. Different producer analyses are not acceptance limits.
SIJ SIMOLD 2311 chemistry reference ↗ SIJ variant comparison names ↗ H13 chemistry comparison ↗
